Isiflo using Moicon© for Factory Space Optimization

Check out how Isiflo, a manufacturer of couplings, established a 3D version of their real life factory to provide a safe and efficient testing environment directly from their web browser.

Isiflo using Moicon© for Factory Space Optimization

For Isiflo, rather than investing considerable time in implementing physical changes live directly in their factory floor - where the risk of failure is very real - the Moicon© Digital Twin replicated their real life factory and turned it into a dynamic 3D-representation, easily accessible directly from their web browser.

Now, Isiflo can create and simulate various layout scenarios and changes trialed and monitored to ensure success before live implementation in their factory.

How was it done? No 3D-model required to get started!

  • Isiflo had no 3D-model
  • Isiflo sent Moicon their available floorplan drawings (E.g. DWG or PDF) and Moicon's modelling team prepared their 3D model withing 48 hours

Check out the steps below!

Step 1: Isiflo sent Moicon their 2D DWG floorplans.

Step 1: Isiflo sent Moicon their 2D DWG floorplans.

Step 2: Moicon modelled Isiflo's factory in 3D based on the DWG files.

Step 2: Moicon modelled Isiflo's factory in 3D based on the DWG files.

Step 3: Two days later Isiflo's 3D model is ready and online.

Step 3: Two days later Isiflo's 3D model is ready and online.

Equip your 3D-model with your 3D assets and equipments by dragging and dropping from your Asset Library™

Equip your 3D-model with your 3D assets and equipments by dragging and dropping from your Asset Library™

For Isiflo, the first step, and the main reason for introducing a Digital Twin, was to ensure that all their facilities managers were on the same page during the process of planning their new layouts. This necessitates a collaborative and easy-to-access Digital Twin platform that is centralized and enterprise-ready by design so that it can be leveraged across different departments in Isiflo.

Tore Flaterud

Tore Flaterud

COO of Isiflo. Moicon helped us implement a easy-to-use and consistent way to capture our factory space accurately and as frequently as needed during our layout planning process.

Moicon's layout capturing solution scales and supports a snapshot system where it is easy to capture a full or partial version of Isiflo's Digital Twin at their desired interval. It's important for Moicon to provide a high 3D fidelity of the model and space, high enough to be able to check small details but without hindering performance. This way Isiflo can compare their generated layout snapshots through time to check differences.

That's the power of Moicon©

Available to everyone, Moicon© Digital Twin allows you to model your physical space digitally.

As manufacturers race toward their own digital transformation, transitioning from paper to digital documentation has become one of the main maturity level indicators. However, intuitive solutions that let you easily retrieve and access digital interfaces and documents are hard to come by - until now.

Get in touch today and let's work together on creating a dynamic 3D-representation of your factory - in the form of a Digital Twin, accessible directly from your web browser.
